Our company provides a complete Paper Roll Conveying and Packaging System designed to automate the finishing stage of your paper production line. This paper mill equipment handles paper rolls from the rewinder all the way to the warehouse, covering conveying, weighing, scanning, coding, wrapping, and labeling. The Paper Roll Conveying and Packaging System includes a barcode printing system, pneumatic roll dividers, pneumatic roll stops, V-shaped chain conveyors, automatic scanning devices, diameter measurement, weighing systems, automatic inkjet printers, fully automatic PET strapping machines, fully automatic radial stretch film wrapping machines, automatic certificate printing and pasting systems, vertical lift conveyors, flat conveyors, and related electrical control systems. This Paper Roll Conveying and Packaging System is a complete, new, and advanced solution. The buyer only needs to provide embedded parts, air supply, and power supply, and the system can run normally. As a key part of your paper mill plant machinery, our Paper Roll Conveying and Packaging System helps you reduce manual labor, improve packaging quality, and increase efficiency in your paper making line.

The Paper Roll Conveying and Packaging System follows a clear and efficient workflow. First, a barcode printing system is placed at the quality inspection station. Operators input roll information and destination into the system, which generates a barcode automatically. The barcode is printed and pasted onto a fixed position on the roll. Rolls coming down from the rewinder roll along a ramp. Some rolls are stopped on the slope by a pneumatic divider, while others roll past it and are stopped on the chain conveyor by a fixed roll stop. The chain conveyor is started manually to move the rolls out, and then the next batch is released. The rolls then enter the weighing and scanning station. The weight information is saved automatically, and the scanning device reads the barcode and saves it to the host computer. The diameter measurement device checks the roll size, and the automatic inkjet printer marks the roll end face. After weighing and coding, the rolls move to the certificate printing and pasting station. The host computer reads the previous data and weight information to form a complete certificate, which is printed and pasted automatically by a robot onto the top of the roll. The rolls then move to the strapping station, where a fully automatic PET strapping machine applies two straps. Next, the rolls go to the film wrapping station for automatic wrapping. Finally, a vertical lift conveyor lowers the rolls to the first floor flat conveyor line, and the forklift operator is notified to move the rolls to the warehouse.

Key design parameters of Paper Roll Conveying and Packaging System:

Beyond our Paper Roll Conveying and Packaging System, we offer complete solutions for your entire paper mill. We supply a full range of paper mill equipment, including pulpers, refiners, screens, cleaners, headboxes, forming sections, press sections, drying sections, calenders, and reeling machines. We can design a complete paper production line for various paper grades, from kraft paper to linerboard. Our team can help you set up a paper processing line from stock preparation to the finished reel. We also offer turnkey paper production line services, taking care of everything from planning to installation. Contact us today to learn more about our Paper Roll Conveying and Packaging System and other paper industry machinery.
