Lubrication System for Writing Paper Machine Project
The Lubrication System serves dryer cylinder bearings, Vac cylinder bearings, guide roll bearings, and the reeling machine. It uses a closed circulating oil system to keep all moving parts running smoothly. Our Lubrication System includes standard lubrication stations with gear pumps, motors, and control cabinets. The system features imported float-type flow meters, group alarms, modular centralized oil supply, and adjustable flow rates for easy observation. As a key part of your paper mill machinery, our Lubrication System helps you reduce friction, prevent overheating, and extend the life of your paper making machine.
In paper mills, lubrication systems often face problems such as oil temperature changes, pressure drops, low oil levels, filter clogging, and pump failure. These issues can cause bearing damage and unexpected downtime on your paper production line. Our Lubrication System solves these problems with a range of advanced features. The oil tank of our Lubrication System has a partition that separates return oil from clean oil. This design helps separate air and water from the oil. Return oil from lubrication points passes through a return oil filter before entering the main tank. This filter can be cleaned while the machine is running. The oil tank includes a thermal cycle, high and low level switches, an electric heater, temperature sensors, and an air filter. For pressure control, the Lubrication System has oil pumps with a main pump and a standby pump. You can select and start the main pump from the paper machine control system. If the main pump stops, the standby pump starts automatically. The oil filter of our Lubrication System has filter elements that can be replaced while the machine is running. A differential pressure display shows when to change the elements. This display also controls an alarm in the paper machine control center. A safety valve is installed on the oil inlet pipe of the filter. The oil cooler of our Lubrication System is a plate heat exchanger. A temperature control valve is installed in the cooling water outlet pipe. The flow meter panel distributes oil to each lubrication point. Each oil inlet pipe on the control panel has a shut-off valve. The control panel has an oil leak tray. Flexible hoses are used for movable lubrication points. Quick-change couplings are used at points that need frequent maintenance, such as the dryer fabric change area.
Beyond our Lubrication System, we offer complete solutions for your entire paper mill. We supply a full range of paper mill equipment, including pulpers, refiners, screens, cleaners, headboxes, forming sections, press sections, drying sections, calenders, and reeling machines. We can design a complete paper production line for various paper grades, from writing paper to packaging paper. Our team can help you set up a paper processing line from stock preparation to the finished reel. We also offer turnkey paper production line services, taking care of everything from planning to installation. Contact us today to learn more about our Lubrication System and other paper industry machinery.
